AXION F26/F36 Series
Vertical Type Packaging Machines
Still deciding? Get samples Still deciding? Get samples
Athapack
Detail
Working with the intermittent motion system, the AXION series reaches the maximum speeds that can be reached using Servo-Motion technology. Thanks to its modular structure, the AXION Series adapts to changes in the market with accessories and apparatus, and realizes various package types with simple settings.
General Features
- Intermittent motion working system
- All surfaces in contact with the product are AISI 304 stainless steel.
- Nitrogen gas blowing system option
- Air conditioning option on electrical panel
- Industrial PC option for remote access
- Static receiver option
- Barcoding (printer) application option
- Option of vacuum application of film puller belts
- Automatic coil change application option
- Parameters and settings are easily made from the 10” LCD Color Touch screen.
- The management of all functions of the machine is provided by the Motion-Controller system.
- All main movements in the machine are performed by independent Servo motors.
- It works on photocell and non-photocell packaging.
- Adhesion is ensured by PID Heat Control System.
- Reel replacement is easily done with the Film Adding Unit.
- With the Auto-Film Centering System, the film is always on axis.
- With the Auto-Film Warp System and Movable Balance Arm, the bobbin is constantly opened with the same tension.
- With the film end sensor, the machine is automatically stopped when the film runs out.
- Security: If any error occurs, the machine is automatically stopped and the error is displayed on the screen.
- Packaging materials; Polypropylene, polyethylene, all laminated films, barrier film, water-soluble film, etc.
- Various Pack Types; pillow pack, gusseted pack, sit-on pack, slit-edge pack and stacked pack.
- It is suitable for different types of filling systems; Volumetric & Screw dosing, Multi-Head & Linear Scales and various liquid piston dosing.
- Complies with CE standards
Technical Details
| Axion F26/F36 Technical Data | ||
| Features | F26 | F36 |
| Mechanical Speed | Max. 90 cycles /min | 70 c /min |
| Package Size | Max . 400mm | 600 mm |
| Package Width | Max . 250mm | 35 0 mm |
| Coil Width | 600 mm | 800 mm |
| Coil Diameter | 400 mm | 400 mm |
| Power Consumption | 5kW | 6 kW |
| Voltage | 380V 3Phase 50Hz | 380V 3Phase 50Hz |
| Air Consumption | 150 l / min | 170 I /min |
| Air Pressure | MIP 6 Bar | Min 6 Bar |
| Weight | 1100 kg | 1300 kg |
| Dimensions (Width x Length x Height) |
1450 x 2250 x 1700 (mm) |
1550 x 2250 x 2170 (mm) |
