Chisel Subsoiler
YTagri
Chisel enables tillage without needing a plough for the harvest. Due to its leg structure, the plough breaks the lower layer and this machine is a suspensory machine for low clod soil which cannot be ploughed during dry summer months.
High working depth tillage is possible with the chisel. Thus, the soil is ventilated, the rainwater on the surface is prevented to be absorbed by the soil for the soil to protect its moisture and the hard layer is broken for the plant roots to easily grow to the bottom.
| MODEL | Number of Tines | Angle of Penetrotion |
Chassis Height (mm) |
Working Depth (mm) |
Furrow Distance (mm) |
Working Width (mm) |
Machine Weight (kg) |
Required Tractor Power (HP) |
||
| CZ 5 | 5 | 30O | 750 | 150-350 | 275 | 1500 | 320 | 40 | ||
| CZ 7 | 7 | 2100 | 400 | 50 | ||||||
| CZ 9 | 9 | 1800 | 510 | 70 | ||||||
| CZ 11 | 11 | 3100 | 590 | 90 | ||||||
| CZ 13 | 13 | 3600 | 670 | 110 | ||||||
| 3CZ 11 | 11 | 2500 | 680 | 90 | ||||||
| 3CZ 13 | 13 | 2900 | 760 | 110 | ||||||
| Big Tines Chisel Plough | ||||||||||
| CZA 7 | 7 | 30o | 870 | 150-350 | 150-350 | 2100 | 465 | 60 | ||
| CZA 9 | 9 | 2800 | 585 | 90 | ||||||
| CZA 11 | 11 | 3100 | 685 | 100 | ||||||
| CZA 13 | 13 | 3600 | 880 | 120 | ||||||
| 3CZA 11 | 11 | 2800 | 780 | 110 | ||||||
| 3CZA 13 | 13 | 3300 | 980 | 140 | ||||||
| Small Tines Chisel Plough | ||||||||||
| CZB 5 | 5 | 30o | 600 | 150-350 | 150-350 | 1300 | 195 | 30 | ||
| CZB 7 | 7 | 1900 | 270 | 40 | ||||||
| CZB 9 | 9 | 2500 | 370 | 50 | ||||||
YANMAR, a century old famous company from Japan, is the world’s leading manufacturer of construction equipment, agricultural machinery and equipment, energy systems, marine and industrial engines.
YTAGRI operates in the export business of agricultural implements and machinery. Company founding purpose is to bring together farmers from all over the world with quality products manufactured in Turkey. Support from YANMAR global network, YTAGRI exports Turkish agricultural implements to many countries in the world including Turkic Republics, Eastern Europe, Africa, the Middle East, Japan and Asia.
YTAGRI with support of YANMAR, combines quality, durability and functionality in its wide product portfolio. YTAGRI all products pass YANMAR’s world-renowned quality and standards.
Certificates Company YTagri
